Product details description
S307 – Cam switch elements
Single pole cam-operated switching elements for 250 A and 300 A
Cam-operated switching elements of Schaltbau are designed for DC and AC applications. Notwithstanding their compact design the series
feature an extraordinary breaking capacity which is owed to the double-break contacts and long contact travel that make breaking the
circuit a safe and reliable job.
Features
●Slim design
●Double-break contacts
●Variants:
●S307 C and M for DC with magnetic blowout
●S307 A and K for AC without magnetic blowout
●Optional arc chamber
Arc chamber/arc chute
●Optional, to be ordered separately
●LK-S307: Arc chamber for cam switch elements S307 C and S307 G
●LK-S307-DC: Arc chute for cam switch elements S307 G/N and S307 C/N with keyed hole for mounting the arc chute with correct polarity,
suitable for high voltages
Special variant
●Presented on this site are only stock items which can be supplied in short delivery time.
●If you need a special variant feel free to contact us. Maybe the type of switching element you are looking for is among our many special designs.
If not, we can also supply customized designs. In this case, however, minumum order quantities apply.
====================================== Download Link ======================================
Safety instructions contactors
S306, S307 – Cam-operated switching elements
