Product details description
AC and DC Contactors
Compact single-pole NO contactor for DC or AC with 1,200 V rated insulation voltage. DC design with blowout magnets and arcing chambers. Frequent switching under load.
The single-pole NO contactor C193 can switch on and carry high currents. It was designed for switching loads frequently. The C193 is
available as an AC or DC contactor. The DC versions are fitted with blowout magnets. The C193A and C193B designs possess electric arc
arcing chambers for DC and AC. The magnetic drive can activated using voltages of 24 to 110 V DC. A snap-action switch reports the
switch state of the main contacts to the higher-level control system.
Developed for use in rail carriages, the C193 also works in extreme ambient temperatures. It is considered to be an especially reliable
piece of switchgear with a longer-than-average electrical service life.
====================================== Download Link ======================================
Safety instructions contactors
C193 -1 pole NO contactors up to 1000 VDC
Contactors C193, C294 — Installation and Maintenance Instructions
C193, C195, C294, C295 – Compact 1-pole and 2-pole contactors up to 1500V
Schaltbau product pictures
